QD

Unidirectional Seal Deslagging Knife Gate Valve

Model:
QDZ43X
Working Pressure:
DN150-DN200 10bar
DN250-DN400 7bar
DN450-DN550 5bar
DN600-DN700 3bar
Design Standard:
MSS SP-81
Flange Standard:
PN10/PN16 150LB 10K TE TD
Face to Face:
MSS SP-81
Testing Standard:
API-598
Operation:
handwheel,electric,pneumatic,hydraulic,sprocket, electro-hydraulic, gear, lever
Main Material:
F55, F53, 2205, CF3M, CF8M, CF8, WCB, GGG40
Disc Material:
F55, F53, 2205, SS310, SS316L, SS316, SS304
Sealing Material:
NBR, EPDM, PTFE, FKM, Graphite, Metal
Packing:
Aramid fiber, high-water based fiber, rubber, PTFE, graphite
Applicable Medium:
Applicable for Dust,Solid Particles,Coal, oil, chemical and so on.Slag, cinder, dislagging recommend.

QD Series The type of unidirectional knife gate valve is sealed between the gate plate and the closed cover. It is mainly metal seal. This type of Valve is preferably installed horizontally. It is widely used in other fields such as power plants and other fields with the advantages of non-jammed materials, solid structure, and long life.
